Full Automatic Adhesive Labeling Machine 6000-80000 B/h 6500W Power

Application

1 , High-Speed Three Sides Labeling Machine apply to label one side or front and back , neck label front and back labels of round, square, flat, ellipse and abnormity bottles in the industry of Cosmetics, Drinks, Cleaning, Detergent, Skin Care Products, Hair Care Products, Oil, Tea etc.

2 , Labels roller outer diameter is 330mm,paper roll inner diameter is 76.2mm.

3 , The machine has advanced HIM and more function, simple operation, compact configuration.

4 , Adopts PLC control, Touch screen software operation

5 , At the same time it has the function of no object no labelling, no label can revise and inspect by itself.

6 , The machine can work separately, and also it can work on line with other machines.

7 , Label max width of Neck label is 125mm,front back label is 195mm.

8 , Diameter of Bottle:Thickness is greater than or equal to 30mm,height is less than or equal to 500mm,

Features:

1 , The servo motor not step motor.

2 , Clutch design, make the label tension force more stable, and easy to improve labeling precision.

3 , Advanced color man-machine interface control system.

4 , Germany Siemens PLC control, high reliability.

5 , Used Germany, Japan inductors.

6 , Machine structure is simple, compact, easy to operation and maintenance.

7 , Can add ribbon typewriter, or heat transfer machine and automatic send bottle opener (optional).

Description of Product

1 , Neck,front,back labels of round bottles would be suited for.

2 , The special design of shaping mechanism,ensure accurate positioning is attached to objects,to achieve accurate labeling.

5, Our machineries used servo motor from famous factory,they can realize the closed loop control to avoid the general stepping motor”the blind phenomenon,high precision subdivision,built in absolute value encoder all this in order to provide high accuracy.

7 , While it has some problems with the labels,running or broken,the pressure between the driving shaft and roller would adjustable,the direction can be adjusted arbitrarily,rather than the ordinary elastic pressing.

8 , The labeling head use double compression rollers structure,ensure that the label paper tension and avoid the label break off phenomenon because of back paper cutting injury,sectional type clutch makes tension more balanced.

Added Details

1 , Touch Screen Control System with 20 sets Job Memory

2 , Labeling speed up to 250 BPM ( according to the length of label )

3 , Simple Straight Forward Operator Controls

4 , Special design for three-side labeling,also added fold label.

5 , On-Screen trouble description which is easy to solve

6 , Most material are made by Aluminum and less are Stainless Frame

7 , Open Frame design, easy to adjust and change the label

8 , Variable Speed with stepless motor

9 , Label Count Down (for precise run of set number of labels) to Auto Shut Off

10 , Stamping Coding Device attached

Advantages

1 , Most component are made by aluminum,cutting the weight and cutting the transportation fees.

2 , The production max speed is about 250BS/min.Labeling accuracy is ±1mm.

3 , The machine’s Using power,dimension,Weight are customized.

Guangzhou Boshang Machinery Manufacturing Co., Ltd.



Guangzhou Boshang Machinery is Founded in 2005, specialized in self-adhesive automatic labeling machines. After more than 12 years effort in development, design,manufacturing, maintenance ,sales and after sale services,we already got our customers’ good reputations in daily chemical, drinks and beverage ,Pharmaceutical ,machine oil industries etc .

We focuese on self adhesive labeling solutions for all types and shapes of packages.if your requirement labeling machines for your production process, we can provide simple or proper solution to suit your specific applications.

We care about the high quality high performance and high end user's using feelling. And happy to share our technological advantage with our valued clients.in the long term cooperation with well-konw enterprise,we have learnt their advanced management experience and technology and gained lots of improvement and innovation.

Boson machinery based on the trends and understanding of automation equipment, has been faith in technological innovation, self-development approach to self-development driven by market demand, market demand lead to long-term development of the enterprise, the company has been a leading technology, superior quality, good technical services，which have a good reputation and get a big support by domestic and foreign enterprises. 80% orders comes to regular customers and customers'recommend.

Recently we solved most difficult oval bottle labeling with fast speed and deformed plastic flat bottle labeling ,and applied a lot of patents.

​Your support and satisfaction is our effort's direction and ​imputus.We will show you our all advantage ,let's grow up together.We are sure that we can work long term and friendly business with you .Because of your trust and our service and machine ..
