CE Automatic Sticker Labeling Machine For Small Carton Corners Sealing

    Buy cheap CE Automatic Sticker Labeling Machine For Small Carton Corners Sealing from wholesalers

    Buy cheap CE Automatic Sticker Labeling Machine For Small Carton Corners Sealing from wholesalers
    • Buy cheap CE Automatic Sticker Labeling Machine For Small Carton Corners Sealing from wholesalers

    CE Automatic Sticker Labeling Machine For Small Carton Corners Sealing

    Ask Lasest Price
    Brand Name : Boson
    Model Number : WT-650GR
    Certification : CE
    Price : 10000USD-38000USD
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 70 Set/Month
    Delivery Time : 15days
    • Product Details
    • Company Profile

    CE Automatic Sticker Labeling Machine For Small Carton Corners Sealing

    Automatic sticker small carton corners sealing labeling machine


    Labeling institution


    1 , Labeling machine head:eight orienations adjustment, the angle can be adjusted freely, easy to paste a variety of difficult and transparent label.


    2 , High elastic sponge scraper and non-powered round extrusion, to ensure that no air bubbles; mechanical structure of machine uses an enhanced rigid design , Simple, generous and stable.


    Application


    1 , The machine is designed for seal labeling on two opposite corners of small pharmaceutical cartons. The system provides complete process in carton separation, hold-down stabilizing, labeling, corner wrap adapting, and missing label detection and rejection to ensure perfect output quality. It is an ideal equipment to connect to high speed cartoners for subsequent corner sealing of the cartons at the end of the line.

    2 , Can quickly switch to a different size cartons , simple to cooperate,orderliness beautiful, clean, easy to wash


    3 , Applicable to all industries carton seal labeling products in daily chemicals, petroleum, machine oil, cleaning supplies, food and beverage, pharmaceutical and so on.


    4 , Special Note: 1, such as double sides labeling of some irregular oval round bottle ,there may add an additional fixed mold labeling, the bottle is too thin, as the case may be labeling not pretty, high unqualified . The price need discussion


    5, Labeling head: new design,more stable,width 200mm,suit max label high 190mm,eight orienation adjustment.

    6, Machine can work with ribbon date printer and injek printer.

    7, When you have a lot of kinds of cartons,when labeling,only need to adjust machine.


    Technical Parameters


    Production speed

    45m/min

    Labeling accuracy

    ±1mm

    Label max width

    190mm

    Bottle diameter

    30-100mm

    Label inner diameter

    76.2mm

    Label outer diameter

    Max330mm

    Outline size

    L2000×W700×1400mm

    Air source

    4-6KG 30L/MIn

    Using power

    220V 50HZ 1200W
