Complete Cycle Rond Bottle Adhesive Labeling Machine Equipment

    Buy cheap Complete Cycle Rond Bottle Adhesive Labeling Machine Equipment from wholesalers

    Buy cheap Complete Cycle Rond Bottle Adhesive Labeling Machine Equipment from wholesalers
    • Buy cheap Complete Cycle Rond Bottle Adhesive Labeling Machine Equipment from wholesalers

    Complete Cycle Rond Bottle Adhesive Labeling Machine Equipment

    Ask Lasest Price
    Brand Name : Boson
    Model Number : WT-630GE
    Certification : CE
    Price : 10000USD-38000USD
    Payment Terms : T/T, L/, Western Union, L/C
    Supply Ability : 40 Set/Month
    Delivery Time : 20days
    • Product Details
    • Company Profile

    Complete Cycle Rond Bottle Adhesive Labeling Machine Equipment

    Complete Cycle Rond Bottle Adhesive Labeling Machine Equipment


    Technical Parameters


    Production speed

    45m/min

    Labeling accuracy

    ±1mm

    Label max width

    190mm

    Bottle diameter

    30-100mm

    Label inner diameter

    76.2mm

    Label outer diameter

    Max330mm

    Outline size

    L2000×W700×1400mm

    Air source

    4-6KG 30L/MIn

    Using power

    220V 50HZ 1200W


    Product Characteristic


    1 , The advanced kind human interface system,on-line helping system,really human-machine

    communicating,it is easy to operate so the workers can operate the machine in several hours.


    2 , The machine adopts the special structure of air driving and labeling rollers with high labeling accuracy.


    3 , The machine is particularly applicable to circular label for big round bottles,high repeat accuracy,without air bladder,with special design,no need the structure of separate bottle it makes the system easier,higher efficiency.


    4 , The range of labels is extended because of hign-power servo motor.Solves the common problem of the insufficient strength.


    5 , The machine adopts our company patent technology.The inaccurate labeling is eliminated largely because of the structure of three rollers capable of locating labeling position,automatically.


    6 , It can be chosen to label one piece or two pieces,and it can label the washing hand liquid bottles in front and back at the same time.


    7 , The machine is applicable to label cylinder bottles for daily chemicals,beverages,pharmaceuticals etc.

    Application

    1 , The machine is apply to the Daily Chemical and Food Industry.


    2 , Labeling max width is 190mm(can be raised according to the require)

    3 , Bottle diameter:30-100mm, Label inner diameter is 76.2mm,max outer diameter is 330mm.


    4 , The air pressure pump of air source is 4-6KG,about 30L/MIn.


    Advantages


    1 , Most component are made by aluminum,cutting the weight and cutting the transportation fees.


    2 , The production max speed is about 45m/min.Labeling accuracy is ±1mm.


    3 , The machine’s Using power,dimension,Weight are customized.


    Medicine PICs
