Sitkcer Automatic Vial Sticker Labeling Machine With Spare Parts
Presentation
Specification
| Production speed | 300pcs/min |
| Labeling accuracy | ±0.5mm |
| Label max width | 130mm |
| Bottle diameter | 10-30mm |
| Label inner diameter | 76.2mm |
| Label outer diameter | 330mm |
| Outline size | L2500×W1200×1600mm |
| Weight | 380KG |
| Using power | 220V 50HZ 1500W |
Application
1 , The machine is apply to label on small round bottle with fast
speed in food ,cosmetic ,pharmaceutical industry,Labeling max width
is 130mm.
2 , Bottles diameter is between 10-30mm
3, We can accept custom according to your labeled samples
4, Bottles from stand to horizontal in conveyor
Advantage
1 , Most component are made by aluminum,cutting the weight and
cutting the transportation fees.
2 , The production max speed is about 500pcs/min.Labeling accuracy
is ±0.5mm.
3 , High speed and accurate labeling make the manufature more efficient.
4 , Apply to various of industry,such as
Pharmaceutical(Ampoules,Injection vials and so on).
Product Characteristic
1. Small structure takes up less space and easy to move and load.
2. Good labeling precision and stability; Neat, no wrinkle, no
bubble.
3. It has powerful function. It can achieve circumferential
position labeling and non-position labeling easily.
4. It satisfy the circumferential position labeling and
non-position labeling on diameter between 10-30mm bottles.
5. It is easy to use and adjust. The new workers can use or adjust
it easily after simple training.
6. Conveyer parts are completely covered to avoid the abnormal
conditions which make the use safer.
7. The clever design which allow user to mechanically adjust some
structure combination and label winding, makes it easy to adjust
the labeling position freely. All these make it easy to change
products and wind labels.
8. Has 2 control methods: automatic and semi-automatic. Workers can
choose either sensor control or feet step control for labeling
according to reality.
9. Whole equipment is mainly made of stainless steel and high level
aluminum alloy. The whole structure is strong and harmonious.
10. Has fault stop function, production counting function.
Machine photo
Labeling samples for reference
